Fine Tuning your MyUsbDrive
You can connect and share one or two USB drives.
If you did not connect your USB drive/s or there is a problem detecting them, the setup wizard will guide you.
Click on No if you haven't connected any USB drives yet.
Download The Full Instructions
If you have just configured your MUD or have replace the USB Drive and find that you can via the MUD, see the connected USB Drive but Can't see any content (Files & folders etc.), then this will be because your USB Drive has more than one Partition.
Connect the USB Drive to a PC and use 'Computer Management' then ' Disk Management' to see the Partitions on the USB Drive. You may be able to delete the additional Partitions and re-format the USB Drive; otherwise you may need to use a third party Disk Manager such as EaseUS Partition Master Free.
Although you can access your MUD via its Host name , it is important to provide your MUD with a fixed IP to ensure reliable connectivity and easier access via the Internet
There are two ways to access and rename your MUD
1- Your MUD directly connected to a Monitor or TV via a HDMI cable
2- Remotely from a PC on your network using PuTTY or MobaXterm (SSH and telnet client)
Download The Full Instructions
1 - How to: Connected to a Monitor or TV:
At the 'Login' prompt enter - pi
At the 'Password' prompt enter
Password = myUSBdr1ve! (default & case sensitive)
Password = ??????? (as re-set by you)
1.1
Enter 'sudo nmtui'
1.2
Select - 'Edit a connection' > Right arrow to select 'OK' and press 'Enter'
1.3
Select - 'Wired connection 1' > and press 'Enter'
1.4
Go to 'IPv4 CONFIGURATION <Manual>' (change from Automatic to Manual)
-Enter the IP you require e.g. 192.168.0.10/24
-Enter 'Gateway' (your Hubs IP address) - Nominally 192.168.0.1
-Enter 'DNS servers' IP addresses
-You can "Google" and find out what your ISP's default DNS servers IP's
-Or use 1.1.1.1 (Cloudflare) & 8.8.8.8 (Google)
-Scroll to the bottom and select 'OK' and press 'Enter'
NOTE: It is recommended to turn off IPv6
1.5
Reboot your MUD for changes to make effect
2 - How to: Connected via PuTTY or MobaXterm:
The process once logged into your MUD via PuTTY or MobaXterm is as above
Next:
Open PuTTY or MobaXterm
Enter your MUD's IP address and click open
At the 'Login' prompt enter - pi
At the 'Password' prompt enter
Password = myUSBdr1ve! (default & case sensitive)
Password = ??????? (as re-set by you)
once logged in; Enter 'sudo nmtui'
Continue as above
We recommend the use of ethernet but WiFi can be used; noting that the performance will be reduced
There are two ways to access and rename your MUD
1- Your MUD directly connected to a Monitor or TV via a HDMI cable
2- Remotely from a PC on your network using PuTTY or MobaXterm (SSH and telnet client)
Download The Full Instructions
1 - How to: Connected to a Monitor or TV:
At the 'Login' prompt enter - pi
At the 'Password' prompt enter
User Name = pi
Password = "as set by you"
1.1
Enter 'sudo nmtui'
1.2
Select - 'Edit a connection' > Right arrow to select 'OK' and press 'Enter'
1.3
Select - 'your Wi-Fi connection (you’ll see the SSID you wish to connect to)' > and press 'Enter'
1.4
Go to 'IPv4 CONFIGURATION
-Enter the IP you require e.g. 192.168.0.10/24
-Enter 'Gateway' (your Hubs IP address) - Nominally 192.168.0.1
-Enter 'DNS servers' IP addresses
-You can "Google" and find out what your ISP's default DNS servers IP's
-Or use 1.1.1.1 (Cloudflare) & 8.8.8.8 (Google)
-Scroll to the bottom and select 'OK' and press 'Enter'
NOTE: It is recommended to turn off IPv6
1.5
Reboot your MUD for changes to make effect
2 - How to: Connected via PuTTY or MobaXterm:
The process once logged into your MUD via PuTTY or MobaXterm is as above
Next:
Open PuTTY or MobaXterm
Enter your MUD's IP address and click open
At the 'Login' prompt enter - pi
At the 'Password' prompt enter
User Name = pi
Password = "as set by you"
once logged in; Enter 'sudo nmtui'
Continue as above
